Hillcrest series

Construction

• 9' Sidewall Height
• Flat Ceilings Throughout
• 2x6 Exterior Walls
• 2x3 Interior Walls
• Nominal 3/12 Roof Pitch
• 30 # Roof Load
• 12” Eaves Entire Home
• 2x6 Floor Joist 16” O.C.
• OSB Tongue & Groove Floor Decking
• Perimeter Heat w/Toe Kick Registers
• Detachable Hitch
• Insulation R 40-21-33

9' Sidewall Height
Flat Ceilings Throughout
2x6 Exterior Walls
2x3 Interior Walls
Nominal 3/12 Roof Pitch
30 # Roof Load
12” Eaves Entire Home
2x6 Floor Joist 16” O.C.
OSB Tongue & Groove Floor Decking
Perimeter Heat w/Toe Kick Registers
Detachable Hitch
Insulation R 40-21-33

Exterior

• 22’ Dormer Front Door Side Per Floor Plan
• 12' Dormer Front Door Side Per Floor Plan
• Lap Siding under Vertical Front Door Side
• Board & Batt in Dormer Peak
• 5/4”x 4” Window Trim Front Door Side
• 30-Year Class “A” Fire Rated Shingles
• 36" 6-Panel Fiberglass Front Door w/Deadbolt
• 36" 9-Lite Fiberglass Rear Door w/Deadbolt
• Low “E” Insulated Vinyl Windows

22’ Dormer Front Door Side Per Floor Plan
12' Dormer Front Door Side Per Floor Plan
Lap Siding under Vertical Front Door Side
Board & Batt in Dormer Peak
5/4”x 4” Window Trim Front Door Side
30-Year Class “A” Fire Rated Shingles
36" 6-Panel Fiberglass Front Door w/Deadbolt
36" 9-Lite Fiberglass Rear Door w/Deadbolt
Low “E” Insulated Vinyl Windows

Interior

• Linoleum Entry
• Shaw® Takeaway Carpet w/Rebond Pad
• Tape & Texture Interior w/Square Corners
• 2 ¼” Base Molding
• 3” Flat Ceiling Crown
• Metal Mini Blinds
• Wood Cornice Valances (N/A with Craftsman Trim)
• White Wood Window Casing and Trim
• T-Panel Doors
• Lever Handles
• 36” Passage Doors per Plan

Linoleum Entry
Shaw® Takeaway Carpet w/Rebond Pad
Tape & Texture Interior w/Square Corners
2 ¼” Base Molding
3” Flat Ceiling Crown
Metal Mini Blinds
Wood Cornice Valances (N/A with Craftsman Trim)
White Wood Window Casing and Trim
T-Panel Doors
Lever Handles
36” Passage Doors per Plan

Mechanical

• Forced Air Electric Furnace
• WI-FI Thermostat
• 50-Gallon Electric Water Heater w/Dual Element
• Whole House Water Shutoff
• Insulated Fiberglass Heat Ducts
• Whole House Water Shutoff at Main
• Shut Off Valves T/O
• Plumb for Washer and Wire for Dryer
• Wire Shelving above Washer and Dryer
• Whole House Fan
• Residential PEX Water Lines
• 200 AMP Service
• Recessed Lights Throughout
• Exterior Recept w/GFI Breaker
• Rocker Switches & Decorator Recepts
• Paddle Fan w/Light in Living Room
• Smoke Detectors w/CO
• Exterior Light at All Exterior Doors

Forced Air Electric Furnace
WI-FI Thermostat
50-Gallon Electric Water Heater w/Dual Element
Whole House Water Shutoff
Insulated Fiberglass Heat Ducts
Whole House Water Shutoff at Main

Kitchen

• Tall Overhead Cabinets
• CS96C Cabinet System
• Shaker Style Cabinet Doors
• Hardwood Cabinet w/Hidden Hinges
• Drawer Over Door Cabinet Construction
• Full Extension Drawer System w/Ball Bearing Guides
• Refer Overhead Cabinet
• Crown Molding on Overhead Cabinets
• Adjustable Overhead Shelves
• Fixed Shelf in Base Cabinet
• 4" Ceramic Tile Backsplash
• HPL Countertop and Selfedge
• 8" Deep Stainless Steel Sink
• Single Lever Kitchen Faucet
• 18 Cu. Ft. Frost Free Refrigerator
• 30" Deluxe Range w/Glass, Clock & Timer
• 30” Vented Range Hood

Tall Overhead Cabinets
CS96C Cabinet System
Shaker Style Cabinet Doors
Hardwood Cabinet w/Hidden Hinges
Drawer Over Door Cabinet Construction
Full Extension Drawer System w/Ball Bearing Guides

Bathroom

• Shaker Style Cabinet Doors
• Hardwood Cabinets w/Hidden Hinges
• Full Extension Drawer System w/Ball Bearing Guides
• 60” 1 Piece Fiberglass Tub/Shower Combo
• 4” Formica Backsplash w/Formica Edge
• China Lavy Sinks
• Metal Single Lever Faucets
• Elongated China Commodes
• Power Vent Fan with Light
• Towel Bar
• Tissue Holder
• 24” x 36” Mirror w/Trim
• Tulip Light over Mirror

Shaker Style Cabinet Doors
Hardwood Cabinets w/Hidden Hinges
Full Extension Drawer System w/Ball Bearing Guides
60” 1 Piece Fiberglass Tub/Shower Combo
4” Formica Backsplash w/Formica Edge
China Lavy Sinks
Metal Single Lever Faucets
Elongated China Commodes
Power Vent Fan with Light
Towel Bar
Tissue Holder
